Microchannel board

  • Classification: Fiber optic image transmission component series
  • Number of views: 1556
  • QR code:
  • Release time: 2021-09-22
  • Product Overview

A microchannel plate (MCP) is an electron avalanche multiplication device. After each channel wall undergoes hydrogen burnback, a semiconductor layer with secondary electron emission characteristics is formed on the surface. When input electrons collide with the channel wall, secondary electrons are generated. Through multiple such collisions, electron output of 104 to 105 times is achieved, thereby achieving the purpose of enhancing weak electrical signals. MCPs are widely used in applications such as low-light imaging and particle detection.

Technical data

Effective plate diameterΦ10 ~ 100mm

Channel apertureΦ5 ~ 50μm

Ratio of entrance-exit≥60%

Electrode materialsNi-Cr

stoving temperature500℃

electronic gain≥104( 1000V)

Resistance30 ~300 MΩ

areal resistance≤100Ω

chamfer angle0 ~20°

ShapeRound,ring, square with / without solid hemming
